#Powerhap piezo actuator driver
The second evaluation kit is suitable not only for the 60-V PowerHap types, but also the 120-V types, and is available in two versions: a driver for one actuator (Z63000Z2910Z1Z1), and driver for up to five actuators (Z63000Z2910Z1Z7). The board is based on the CapDrive driver architecture from Boréas Technologies, a developer of ultra-low-power haptic technologies with which TDK Electronics has signed an agreement.Īccording to the company, the main features of the BOS1901 piezoelectric driver are its small dimensions, low current consumption, and fast response times.
#Powerhap piezo actuator code
The BOS1901-Kit development kit is designed for and includes three 60-V actuators. The ordering code for the kit is Z63000Z2910Z1Z44. The 15G type is a 26 mm × 26 mm devices that can achieve a displacement of more than 200 μm and can generate an acceleration of 15 g forces of up to 20 N.TDK Corporation has launched two evaluation kits to test haptic feedback features that can be enabled with PowerHap piezo actuators. 2 Description The BOS1901-KIT is a Development Kit to help users who want to get familiarized with the BOS1901 Piezo Haptic Driver IC. The 12.7 mm × 12.7 mm 7G type achieves a displacement of up to 100 μm and can generate an acceleration of 7 g forces of up to 5 N. Starter Set: TDK PowerHap 12042 lateral Premium Set: TDK PowerHap 1204 lateral, 0904 lateral, 0909 square, Midé Technology PPA-2014 bending.
The 2.5G type achieves a displacement of up to 35 μm and can generate an acceleration of 2.5 g forces of up to 5N in a 9mm × 9 mm footprint. With the PowerHap and PiezoHapt product families, TDK provides cutting-edge high-performance haptic solutions for a very. The PowerHap actuators are available in three types, each in a RoHS-compatible ceramic body with titanium cymbals for displacement amplification. PowerHap: Unrivalled Acceleration, Force, and Response Time The actuators of the PowerHap family are based on multilayer piezo plates with copper inner electrodes. In this way, the actuator enables designers to develop custom high-definition haptic feedback profiles that users expect from cutting-edge HMIs. PowerHap piezo actuator with haptic feedback and integrated sensor functionality offers unrivalled performance in terms of acceleration, force and response. The innovative PowerHap piezo actuator with haptic feedback and integrated sensor functionality is now available in three compact types 0909H011V060, 1313H018V1H023V120 which can achieve an very high acceleration of 2.5g, 7g and 35g, respectively, under a load of 100 grams. As a result, the actuators have no significant frequency or amplitude limitations for customized haptic feedback. 7G, TDK Group Co.) is also integrated in the base platform for generating vibrotactile feedback on the. Unlike conventional electromagnetic solutions, PowerHap actuators can excite the entire stimulation range between 1 Hz and 1000 Hz. At the same time, a piezoelectric actuator (PowerHap.
TDK EPCOS PowerHap actuators, available from Mouser Electronics, are based on multilayer piezo plates with cost-effective copper inner electrodes, which allow designers to drive the actuators with relatively low operating voltages up to 120 V.
